Intermediate modular relay 3 contacts 16A 12V AC/DC

Product ID:

Main specifications

Voltage type for actuating	Переменный (AC)
Rated control supply voltage Us at DC, В	24
Rated control supply voltage Us at AC 50HZ, В	400
Number of contacts as change-over contact	0
Nominal current, А	10

The modules are designed for installation in front socket panels and boxes boxes for completion of sockets in work seats.

Voltage type for actuating	Переменный (AC)
Rated control supply voltage Us at DC, В	24
Rated control supply voltage Us at AC 50HZ, В	400
Number of contacts as change-over contact	0
Nominal current, А	10
Type of switch contact	Одинарный контакт
Number of groups of switching contacts	3
With signal lamp	Нет
Type of electric connection	Винтовое соединение
Drive, polarization	Определенная полюсность
Height, мм	35
Width, мм	80.0
Nominal operating voltage DC contacts, В	24; 48; 110; 220; 400
Degree of protection (IP)	IP66
Control coil power at DC 12 V, Вт	1.6
Number of contacts as normally open contact	0
Mechanical wear resistance, циклов	20000
With forced-guided contacts	Да
Complete with socket	Нет
Nominal operating voltage AC contacts, В	230; 400
Electric wear resistance, циклов	6000
Ambient temperature, °C	-40...50
Control coil power at AC 12 V, ВА	2.0
Drive, switching attitude	Моностабильное
Depth, мм	1570
Number of contacts as normally closed contact	0
With detachable clamps	Нет
