| Voltage type of supply voltage | Перемен./постоян. (AC/DC) |
| Power output, Вт | 120 |
| Nominal output current, А | 10.00 |
| Input voltage range, В | AC (90...264); DC (127...370) |
| Nominal DC output voltage, В | 12 |
| Output Voltage Tuning Range, В | 12...14 |
| Type of overvoltage protection | Отключение |
| Relative air humidity | 20...90% |
| EFFICIENCY, процентов | 85 |
| Short-circuit-proof | Да |
| Degree of protection (IP) | IP20 |
| Rail mounting possible | Да |
| Output current range, А | 0...10,00 |
| Power consumption, ВА | - |
| Depth, мм | 119 |
| Height, мм | 124 |
| Width, мм | 45 |
| Electrical strength input-case, кВ | 1.5 |
| Insulation resistance at 500V input-case, МОм | 10 |
| Threshold of output current limitation, процент от номин тока | 105...130 |
| Pollution degree | 2 по ГОСТ IEC 60947-1 |
| Width in number of modular spacings | 3 |
| Connection capability, мм² | 0,5...6 |
| Own consumption current, А | < 0,035 |
| Impact of load, процентов | 1,0 |
| Temperature factor, процентов | ±0,03% (категория С по ГОСТ IEC 61204) |
| Influence of supply voltage, процентов | 0,5 |
| Insulation resistance at 500V I/O, МОм | 10 |
| Mean time between failures at 25 °С, тысяч часов | 500 |
| Electrical strength I/O, кВ | 3 |
| Peak starting current at input 230V, А | 35 |
| Modular version | Нет |
| Insulation in accordance with GOST 12-2-091 | Усиленная |
| Altitude above sea level, м | < 6000 |
| Type of overload protection | Ограничение выходного тока |
| Maximum dop-my output voltage off, процентов | 1 |
| Electrical strength output-case, кВ | 0.5 |
| 1st secondary output voltage, В | 12 |
| Rated supply voltage at DC, В | - |
| Frequency range, Гц | 47...63 |
| Max. output current 1, А | 10.00 |
| Insulation resistance at 500V outlet-case, МОм | 10 |
| Nomin power at air temperature 25 °С, Вт | 120 |
| Output voltage stabilized | Да |
| Overvoltage protection actuation range, В | 15,0...18,0 |
| Over voltage category | 2 |
| Mounting method | DRA (на DIN-рейку) |
