Terminal block SMK773-328 IEK
Main specifications
| Number of clamp positions | 8 |
| Connection position | Сбоку (поперечное) |
| Nominal cross section, мм² | 2,5 |
| Connectable conductor cross section fine-strand without cable end sleeve, мм² | 1,5...2,5 |
| Connectable conductor cross section solid-core, мм² | 0,75...2,5 |
Description
The compact energy-saving lamps (types KEL, KL) are used as alternative light sources to incandescent lamps. The energy-saving lamps are designed for use in outdoor and indoor luminaires for industrial, social and household facilities. The high power energy-saving lamps (type KEL) are designed for use in outdoor luminaires and also for indoor lighting in industrial and public buildings. They substitute the incandescent lamps of power 200–1250 W. The compact energy-saving lamps of ECO series (type KELR) are designed for mass replacement of 75–100-watt incandescent lamps of main sizes installed in lighting systems in residential and public premises. KEL and KELR lamps comply with requirements of Customs Union Technical Regulations TR TS 004/2011, TR TS 020/2011, IEC 60968 and Russian Federation Government Decree No.602 of 20.07.2011. KL lamps comply with requirements of Customs Union Technical Regulation TR TS 004/2011, IEC 61199 and Russian Federation Government Decree No.602 of 20.07.2011.
Design Features
Specifications
| Number of clamp positions | 8 |
| Connection position | Сбоку (поперечное) |
| Nominal cross section, мм² | 2,5 |
| Connectable conductor cross section fine-strand without cable end sleeve, мм² | 1,5...2,5 |
| Connectable conductor cross section solid-core, мм² | 0,75...2,5 |
| Colour | Серый |
| Nominal current, А | 24 |
| Nominal voltage, В | 400 |
| Type of electrical connection | Фиксатор/защелка |
| Ambient class | УХЛ3 |
| Nominal DC operating voltage Ue, В | 220 |
| Connectable conductor cross section multi-wired, мм² | 1,5...2,5 |
| Mechanical Execution Group | М3 |
| Suitable for flexible core | Да |
| Maintainability | Нет |
| Operation temperature, °C | -25...60 |
| Nominal Attachment Capacity, мм² | 0,75...2,5 |
| Type of electrical connection 2 | Фиксатор/защелка |
| Degree of protection (IP) | IP20 |
| Rated insulation voltage Ui, В | 660 |
| Relative air humidity | ≤ 90% |
| Width, мм | 19.5 |
| Transparent | Нет |
| Nominal operating AC voltage Ue, В | 400 |
| Conductor cross section flexible (fine-strand) with cable end sleeve, мм² | - |
| Suitable for multi-wire core | Да |
| Height, мм | 13.6 |
| With operation lever | Нет |
| Suitable for solid core | Да |
| Length, мм | 24.2 |
