ARMAT Additional contact transverse contact DKP-11 GV3P IEK
New
Product ID:
Main specifications
| Number of contacts as normally open contact | 1 |
| Number of contacts as normally closed contact | 1 |
| Number of contacts as change-over contact | 0 |
| Compatibility | MPCB ARMAT |
| Mounting method | Верхнего монтажа |
Specifications
| Number of contacts as normally open contact | 1 |
| Number of contacts as normally closed contact | 1 |
| Number of contacts as change-over contact | 0 |
| Compatibility | MPCB ARMAT |
| Mounting method | Верхнего монтажа |
| Nominal current AC-15 with nominal operating voltage 230V, А | 0.30 |
| Nominal current DC-13 with nominal operating voltage 110V, А | 0.15 |
| Width, мм | 45.0 |
| Weight, кг | ≤ 0,1 |
| Conditional heat current of additional contact, А | 6.0 |
| Rated operation current Ie at AC-15, 230 V, А | 0,3 |
| Height, мм | 31.1 |
| Rated insulation voltage Ui, В | 690 |
| Degree of protection (IP) | IP20 |
| Type of electric connection | Винтовое соединение |
| Nominal rated voltage, В | 48/130/240/415 |
| Wear resistance, циклов | 50000 |
| Depth, мм | 8.7 |
| Nominal current AC-15 with nominal operating voltage 400V, А | 0.30 |
| Conductor cross section, мм² | 0,75...1,5 |
| Nominal current DC-13 with nominal operating voltage 60V, А | 0.15 |
| Optical defect indication | Нет |
| Nominal current DC-13 with nominal operating voltage 48V, А | 0.15 |
