Control button LAY5-BS542 "Mushroom" emergency fixed positions IEK
Product ID:
Main specifications
| Hole diameter, мм | 22 |
| Spring-return | Да |
| With signal lamp | Нет |
| Colour button | Красный |
| Type of button | Грибовидная |
Description
Applied for screw connection of conductors, protecting wires from damage and excluding possibility of short circuit to the frame of electric unit. Insulation frame is made of white non-flammable polystyrene or transparent polyethylene. Terminal block and screws - latten alloy.
Design Features
Specifications
| Hole diameter, мм | 22 |
| Spring-return | Да |
| With signal lamp | Нет |
| Colour button | Красный |
| Type of button | Грибовидная |
| Lamptype | Не применимо |
| Voltage type | Перемен./постоян. (AC/DC) |
| Switching function latching | Да |
| Degree of protection (IP) | IP40 |
| Number of contacts as normally closed contact | 1 |
| Number of command positions | 1 |
| Suitable for illumination | Нет |
| Number of contacts as normally open contact | 0 |
| Number of normally open contacts | 0 |
| Nominal rated current, А | 0,6 ... 10 |
| Number of normally closed contacts | 1 |
| Number of change-over contacts | 0 |
| Height meter opening, мм | - |
| Supply voltage lamp, В | - |
| Nominal rated voltage, В | 110/230/400/600 |
| Lamp socket | Не применимо |
| Width in number of modular spacings | - |
| Number of contacts as change-over contact | 0 |
| Construction type lens | Нет |
| Width opening, мм | - |
| Type of electric connection | Винтовое соединение |
