L-pixel 3/150/K15/740/R5/01/MT-KM/I1-D3/220AC IP66 RAL7035 LEDEL
Product ID:
Main specifications
| Max. system power, Вт | 150 |
| Rated luminous flux acc. IEC 62722-2-1, лм | 24000 |
| Degree of protection (IP) | IP66 |
| Material housing | Прочее |
| Colour housing | Светло-серый |
Description
The vertical external rotation of 45 ° is designed to organize the rotation of the cable route in the vertical plane. The accessory of the accessory with the tray is carried out at the expense of the telescopic connector. Suitable for all types of leaf trays of the ESCA series. The cover for the accessory is ordered separately. The accessory is made of steel galvanized by Senziri (a protective layer of zinc at least 5-10 microns).
Design Features
Specifications
| Max. system power, Вт | 150 |
| Rated luminous flux acc. IEC 62722-2-1, лм | 24000 |
| Degree of protection (IP) | IP66 |
| Material housing | Прочее |
| Colour housing | Светло-серый |
| Power factor | ≥ 0,95 |
| Dimming depending on the control mechanism | Нет |
| Ambient class | УХЛ1 |
| Light outlet | Прямой |
| Lamp power, Вт | 150 |
| Suitable for lamp power, Вт | 150 |
| Dimming DALI | Нет |
| Dimming DMX | Нет |
| Fire resistance "D" | Нет |
| Dimming LineSwitch | Нет |
| Suitable for number of lamps | 3 |
| Colour rendering index | 70-79 (класс 2A) |
| Dimming 1-10 V | Нет |
| Energy efficiency class of the built-in lamp | A++, A+, A (LED) |
| Suitable for surface mounting | Нет |
| With movement sensor | Нет |
| Length, мм | 492 |
| Type of wiring | Оконечная |
| With light sensor | Нет |
| Colour cover | Нет |
| Power factor | ≥ 0,95 |
| Light distributor | Рассеивающая линза или панель |
| Voltage type | Переменный (AC) |
| Type of surface | Матовый (-ая) |
| Colour of light | Белый |
| Control unit included | Нет |
| Light distribution class | П |
| EFFICIENCY, процентов | 90 |
| Lamptype | Светодиодная незаменяемая |
| Radiation angle | 15 |
| Material cover | Полиметилметакрилат (PMMA) |
| Height/depth, мм | 78.2 |
| Fit for monitor workplace | Нет |
| With lamp | Да |
| Colour temperature, К | 4000 |
| Type of current | Переменный |
| Luminaire energy efficiency, лм на Вт | 160.0 |
| Light sharing | Симметричный (-ое) |
| Suitable for suspended mounting | Да |
| Energy efficiency class of the provided exchangeable built-in lamp | A+ |
| Dimming with push-button | Нет |
| Suitable for emergency lighting | Нет |
| Type of grid | Нет |
| Dimming phase cut-on | Нет |
| Suitable for light line configuration | Нет |
| Outer diameter, мм | - |
| Suitable for ceiling mounting | Да |
| Dimming GPRS | Нет |
| Filament test according to IEC 60695-2-11 | 650 C - 30 s |
| With socket outlet | Нет |
| Nominal voltage, В | 230 |
| Protection class | I |
| Dimming 0-10 V | Нет |
| Suitable for wall mounting | Нет |
| Lamp holder | Прочее |
| Suitable for built-in mounting | Нет |
| Special application | Прочее |
| Dimming potentiometer (integrated) | Нет |
| Dimming DSI | Нет |
| Light colour category | Нейтральный (холодно-белый) 3300-5300 К |
| Luminous flux pulsation factor, процентов | ≤ 2 |
| Nominal frequency, Гц | 50 |
| Width, мм | 214.0 |
| Type of gear | Светодиодный драйвер |
| Operating temperature range, °C | -60…40 |
| Mounting height/depth (embedded), мм | - |
| Dimming Touch and Dim | Нет |
| No dim function | Да |
| Build in insulated ceiling, fire-resistance "F with roof" | Нет |
| Power supply energy efficiency index (EEI) | A2 BAT |
| Dimming manufacturer's proprietary system | Нет |
