Electronic hygrostat UCCG from 40 to 90% RH IEK

Description

This ATS system provides uninterrupted power supply to one group of consumers from two independent power supply sources (inputs), hereinafter conventionally designated as main and backup, and DGU. At the same time, uninterrupted power supply is achieved by switching consumers from the main source of power supply to the backup one - in case of unacceptable deviations of the electricity parameters at the main input, as well as at the DGU - in the event of a simultaneous deviation at both inputs.

We provide standard circuit diagrams solutions for low-voltage complete power distribution devices. These are not finished products, they are not assembled by us. You can order components according to the specification from partners (the package contents are indicated in the product card below) and assemble the ATS yourself using the attached diagrams and drawings, or contact our partners involved in the assembly of electrical panels, section "Where to buy", Partner type - assembler: http: //www.iek.ru/products/where_to_buy/

Advantages

  • Made in strict accordance with GOST.
  • They have high mechanical and anti-corrosion properties.
  • A wide range of nomenclature provides versatility.
  • High reliability and ease of installation.
Electronic hygrostat UCCG from 40 to 90% RH IEK

Design Features

Specifications

Adjustable setting value for relative air humidity, процентов40...90
Nominal rated voltage, В240
Rated current In, А-
Contact typeМагнитный (геркон)
Mounting methodБезвинтовое зажимное крепление
Maximum start-up current, А16
With digital indicationНет
Hysteresis, процентов5±1
RAL-number7035
Ambient classУ2.1
Material housingПластик
Operating temperature range-60...60
Degree of protection (IP)IP20
ColourСерый
Maximum switching capacityAC: 240 В / 120 В, 8(1,6) А; DC: 100 Вт при 24 В
Type of switch functionПереключающий контакт
