T -piece 100x600 IEK HDZ

Description

Perforated Z-shaped profile is designed for installation of cable carrying systems, heating, ventilation and air conditioning systems, as well as for installation of metal shells, control panels, alarm systems, lighting equipment and other electrical appliances. The peculiarity of the design of the profile is that it can be fastened both with studs onto the ceiling and on the walls or floor with anchors and dowels with posterior installation of equipment on it. Perforated Z-shaped profile has the ability to withstand numerous bendings and unbendings, maintaining its shape and physical properties. Therefore, it can be used in structures under constant dynamic loads and vibration.

Design Features

Specifications

Cable tray width, мм600
Cable tray height, мм100
MaterialСталь
Width, мм600
Length, мм730
Wide span modelНет
Stainless steel, pickledНет
Construction typeТройник горизонтальный
Suitable for circuit integrityНет
Metal thickness, мм0,8
ColourСветло-серый
Material qualityПрочее
Width branch, мм600
Surface protectionПокрытие методом горячего погружения
Weight, кг9,5
Ambient classУ1, ХЛ1, УХЛ1, УХЛ5, ОМ1
RAL-number7047
Degree of protection (IP)IP20
Height, мм100
ModelИнтегрированный разъем
