Aluminum lug with a breakaway head AMN 70-240 up to35 kW IEK
Product ID:
Main specifications
| Nominal cross section, мм² | 70...240 |
| Bolt dimension metric (M..) | 19 |
| Width | 33.0 |
| Length | 114.0 |
| Number of screws | 2 |
Description
The induction motors are widely used in numerous fields: processing and extractive industries, construction and communal services, power engineering and transport. The electrical motors are indispensable devices used in fans, pumps, conveyors, processing machine-tools, mixers, handling mechanisms, shutters and gates, compressors, etc.
Design Features
Specifications
| Nominal cross section, мм² | 70...240 |
| Bolt dimension metric (M..) | 19 |
| Width | 33.0 |
| Length | 114.0 |
| Number of screws | 2 |
| Surface protection | Без покрытия (голый) |
| Material | Алюминий |
| Cross section form | Многопроволочная круглая/секторная жила |
| Moment of screw head failure during installation of line cabs, Нм | 40...49 |
| Insulation | Нет |
| Ambient temperature, °C | -50...+95 |
| Colour insulation | Прочее |
| Weight, кг | 0,252 |
| Number of screws | 2 |
Documents
Passports
