Locking clamp CF40 IEK
Product ID:
Main specifications
| Suitable for pipe diameter, мм | 40 |
| Type of fastening | Отверстие под винт |
| Material | Ударопрочный полистирол |
| Colour | Серый |
| RAL-number | 7035 |
Description
Modular circuit breakers (MCB) VA47-60 with a breaking capacity of 10kA are designed to automatically turn off the power supply in the event of overcurrents. Recommended for use in group panels (apartment and floor), as well as in the accounting and distribution boards of administrative and residential buildings with increased electrical load, as well as for the protection of industrial electrical installations.
Advantages
- VD1-63 type A RCCB is a reliable noise-immune electromechanical protective cut-out device that is capable, in contrast to RCCB of type AS, to ensure a universal protection against electric shock in case of accidental unintentional contact with a conductor and against leakage currents.
- Good electric wear resistance: at least 4000 switching operations.
- Rated conditional short-circuit current is 4500 A.
- Wide range of rated currents (16, 25, 32, 40, 50, 63 А)
- and rated tripping differential currents (10, 30, 100 mA).
- Quick installation using the latch with double locking.
- Soldered-on material with silver on the contacts.
- Notches on the terminal clamps reduce the heat loss and increase mechanical strength of the connection.
- The load can be connected to either upper or lower terminals.
- Wide range of working voltages for operation monitoring device (110 to 265 V for 2-pole version and 200 to 460 V for 4-pole version).
- Design of the main contacts of 4-pole VD1-63 type А RCCB provides for early make and delayed break of neutral contact, thus preventing voltage unbalance in the load as in case of broken mains neutral.
Design Features
Specifications
| Suitable for pipe diameter, мм | 40 |
| Type of fastening | Отверстие под винт |
| Material | Ударопрочный полистирол |
| Colour | Серый |
| RAL-number | 7035 |
| Closed | Нет |
| Tackable | Да |
| Ambient temperature, °C | -10...60 |
| Max. number of tubes | 1 |
| Mounting temperature, °C | -10...60 |
| With inlay | Нет |
