It is recommended to read the instruction manual before starting to work with the program
Software functionality:
Software functionality:
- Design and layout of cable structures of any complexity in three-dimensional space
- Obtaining formatted plans, sections of cable structures
- Generating specifications based on model elements
- Identification of interdisciplinary clashes in the project.
The composition and structure of the catalog are implemented taking into account the requirements of GOST
The specification counts the following elements:
- Cable trays and ladders with covers
- Tray and ladder accessories (connectors, cover clamps and dividers).
Обучающий видеоролик
